SPECIFICATIONS

Key Features

3MP Super HD Video Quality

The camera records in 3MP (2304 × 1296) resolution, producing video that is significantly clearer than standard 1080p cameras. This improved image quality helps identify faces, vehicles, and important details in recorded footage.

PTZ Pan-Tilt Coverage

With motorized PTZ functionality, the camera can rotate and tilt remotely through the mobile app, providing wide-area surveillance with minimal blind spots. PTZ cameras allow users to monitor larger areas compared to fixed cameras.

AI Human Detection

Built-in AI human detection technology identifies people specifically rather than general motion, helping reduce false alarms caused by animals, rain, or moving objects. When human movement is detected, the system sends instant alerts to the user’s smartphone.

Color Night Vision

The camera features infrared LEDs and built-in spotlights to support both black-and-white night vision and full-color night monitoring. This ensures clear surveillance even in low-light or nighttime conditions.

Two-Way Audio

A built-in microphone and speaker allow real-time communication. Users can listen to activity near the camera and speak to visitors, delivery drivers, or warn intruders directly through the mobile app.

Motion Alerts & Smart Alarm

When suspicious activity is detected, the camera can trigger instant push notifications, activate spotlights, or sound a siren alarm to deter intruders.

Wireless WiFi Connection

The camera connects to 2.4GHz WiFi networks, allowing live viewing, playback, and camera control through a smartphone application from anywhere.

Weatherproof Outdoor Design

The durable housing is designed for outdoor environments, providing protection against rain, dust, and temperature changes for reliable year-round operation.

---

Technical Specifications

• Resolution: 3MP (2304 × 1296)

• Camera Type: PTZ (Pan-Tilt-Zoom)

• Connectivity: 2.4GHz WiFi wireless

• Night Vision: Infrared + color night vision with spotlight

• AI Detection: Human detection with smart alerts

• Audio: Built-in microphone and speaker (two-way audio)

• Storage: MicroSD card and optional cloud storage

• Compression: H.264 / H.265

• Power Supply: DC power adapter

• Weather Rating: Outdoor waterproof design

---

Typical Applications

This camera is ideal for:

• Home security monitoring

• Driveway and garage surveillance

• Front door and yard monitoring

• Small business security

• Warehouse and parking lot surveillance

AI Functions: Human Detection

Brand Name: H.VIEW

Camera APP: O kam pro

Color Night Vision: Yes

Connectivity: WIFI(2.4GHz)

High Definition: 3.0 Megapixels

High-concerned chemical: None

IP Rating: IP66

IR Distance(m): 20

Installation: Normal

Lens (mm): 3.6mm

Lens Quantity: Single Lens

Megapixels: 3 MP

Model Number: QC6

Power Source: Normal

Power Supply: Normal

Rechargeable Battery: None

Scene: Indoor and outdoor

Style: PT Camera

Supported Mobile Systems: Android,iOS

Supported Operating Systems: No

Video Compression Format: H.264,H.265

Viewing Angle : 90°

Whether or Not 50Vac or 75Vdc or Higher Power Supply: No

Zoom: 8x

Zoom type: Digital zoom
